Double directions shooting will be helped to find out small foreign objects with different angles photos.
Full-automatic operating environment - Automatic start up and shut down with any complicated operation.
High-precision sensor - With high-precision X-ray linear sensor, image of small size foreign object can be taken.
Dual monitors - 2 monitors are included as standard. During the inspection, up to 6 images can be displayed at a time.
Full colour display - full colour inspection screens make the detection of foreign objects easier.
Photographing speed can be adjusted for each products.
Energy-saving function - Depending on the operational aspect, automatically control and reduce power consumption.

Technical Specifications

Model	HNX-560	HNX-665	HNX-560DS	HNX-665DS
Capture method	Single Direction		Double Direction
Belt width (mm)	660
Minimum effective width (mm)	518	612	518	612
Aperture size (mm)	665 X 300 (W)
Line Sensor	High Resolution straight type line sensor
X-ray tube voltage	30 ~ 80 kV
X-ray tube Current	0 ~ 3 mA
LCD size	23 inch monitor (dual monitors)
Memory	8GB
HDD	1TB
Dimensions	2,130 X 990 X 1,475 (H)
Power Consumption	0.8kVA		0.9kVA
Machine weight	620kgs	620 kgs	650kgs	650kgs

Hashima-KM Garment X-Ray HNX-560 X-Ray Inspection
