E-Line KAP Small-Power Busbar System (40 A – 63 A)

The E-Line KAP Busbar System is engineered for efficient small-power distribution in settings such as workshops, light manufacturing, and sewing or hand machine areas. Rated up to 63 A, it delivers reliable energy delivery with a compact, safe, and easy-to-install design. Fully insulated conductors and tin-plated copper ensure both operator safety and long-term performance. Its modular plug-in architecture, with outlets every 75 cm, enables flexible load placement. Manufactured to rigorous IEC standards and backed by ISO-certified production, the E-Line KAP provides a trusted and adaptable solution where small-power connectivity is needed.

• Designed for small-power applications, typically in the 40 A to 63 A range
• Fast, safe installation using silver-plated spring contacts and a single-bolt locking mechanism
• Full-length insulation over conductors for enhanced safety—even if the housing is compromised
• Offers up to 5-conductor configurations, including phase, neutral, and optional grounding conductor options
• Conductors made of electrolytic copper with tin plating to minimize oxidation and contact resistance
• Plug-in points spaced every 75 cm as standard, customizable as needed
• Silver-plated joint contacts for minimal contact resistance and reliable performance
• Built in compliance with IEC 61439-1/6, tested under full type test cycles, and produced with ISO 9001 / 14001 quality standards
